PVDF

Polyvinylidenfluorid

PVDF is a high tech flour plastic, which has many of the same qualities as PEEK, but is cheaper.

PVDF is suitable for use in liquids - eg hot water, washing machines and chemicals.

PVDF has a high chemical resistance and is highly suitable for industry where there is a need for a material that can withstand acids, bases and organic solvents.

Trade names of raw materials and semi-finished products:

  • Symalit®
  • Kynar®
  • Solvay Solef®

Linatex supplies both semi-finished and finished products, as required. Documentation for quality and short delivery times makes Linatex a good partner.

What is PVDF used for

Application temperature normally from approx. 0 ° C up to 140 ° C - briefly up to 150 ° C
Density usually approx. 1.76-1.79 g/cmᶟ

Advantages:

  • High temperature resistance to approx. 150 ° C
  • Great chemical resistance
  • Not attacked by acids, bases and most organic solvents
  • UV-resistant
  • Not attacked by microorganisms
  • Good electrical and dielectric properties
  • Very low water absorption

Limitations:

Call creep resistance.

High density versus other plastic types.

Infested by molten alkali metals, in fluorine gas, acid difluoride and chlorotrifluoride.

Limited wear resistance.

Limited strength.

Applications:

Electrical applications, electrical machines, gaskets, washing machines, pipes, filters, coating in chemical equipment, electrical insulation materials, fine mechanical details, etc.

Linatex is a member of EPDA and IAPD and is subject to ongoing control by the Danish Food Administration

Please note that it is the end user who is responsible for the materials used to comply with applicable laws and regulations.

Linatex uses a Zeiss 3D measuring machine to ensure that deliveries meet the desired dimensions.

We will be happy to help you with advice, drawings and specifications, so the final product will be right.

Linatex stands for proven quality in all products.
